Experienced supplier of Gantry machining center series

Gantry machining center series

Zhongshan Xiangzhi mechanical equipment Co., Ltd is one of the toppest Gantry machining center series in China.During these years of exporting , Zhongshan Xiangzhi mechanical equipment Co., Ltd now has rich experience in the worldwide markets

Tel: +86-13715675215 E-mail: ioyq0828@gmail.com E-mail: ouzhibing168@gmail.com

Feature

Specification

Mechanical Features:

1. The whole cast iron bed, one-piece pillar beam cast iron structure, precision grinding machine processing, ensure mechanical precision.

2. X, Y, Z three axis type import moment true line guide rail with high precision, strong load bearing capacity, rapid displacement position precision is high.

3. High precision grinding ball rod, nut, high precision, to ensure long time mechanical error is small.

4. High power, high speed oil cooled spindle, precision ER elastic clamp series, precision number, the deflection is small.

5. Senior meehanite cast iron material, the structure is the tempering treatment to eliminate internal stress, to ensure the best rigid precision is persistence.

Project	UNIT	XZ-960	XZ-1260	XZ-1680
X/Y/Z axes	mm	900/650/400	200/650/400	1650/850/400
Distance from spindle end to worktable	mm	120-720	150-750	170-870
Spindle specifications		Bt40	Bt50	Bt50
Distance from spindle center to column guard	mm	665	785	810
Worktable area	mm	900*650	650*1200	850*1650
Maximum worktable load	kg	600	1200	1600
Spindle motor power	kw	4.5	7.5	11
X-axis servo motor	kw	2.0	2.3	4.5
Y-axis servo motor	kw	2.0	2.3	4.5
Z-axis servo motor	kw	2.3	4.5	4.5
X/Y-axis rapid traverse rate	m/min	36	18	18
Z-axis rapid traverse rate	m/min	36/36	18/18	18/18
Cutting feed rate	mm/min	0-12000	0-6000	0-6000
Positioning accuracy			jis±0.028/300
Repeatability			jis±0.028/300
Tool magazine capacity	Put	12	12	12
Machine weight	kg	2600	Approximately 3800	Approximately 6300
Machine dimensions	m	2.8x2.4x2.6	3.2x2.8x2.8	4.3x3.2x3.25
